WLA - Work bench light fixture, Workstation light fixture, Work bench lighting, Workstation lighting


WLA LED mounted workstation system light is an ideal solution for manufacturing, assembly or quality control procedures, and metalworking environments - any area where quality lighting is essential. Four lengths allow for matching the light to the workbench to obtain the broadest light source possible. The strong anodized aluminum housing and sealed construction protect the inner workings from environmental dust, etc. from entering the fixture. 5000K color temperature with CRI>80 offer bright, glare-free light for visual clarity. All models are designed for thru-wire capability.

  • Work bench light fixture
  • Broad light output for assembly workstations
  • 5000K color temperature with CRI>80
  • Four lengths to match any work space size
  • 50,000 hours maintenance-free LED technology
  • All models designed for thru-wiring capability
  • Strong anodized aluminum housing
  • Sealed to protect inner workings from environmental dust and other particles
Part No: 113470000-00800170
Model: WLA 1100/850
Length: 17.7"
Wattage: 15W
Lumens: 1100
Spec Sheet:  113470000-00800170.pdf


Part No: 113475000-00704990
Model: WLA 3000/850/T
Length: 35.4"
Wattage: 37W
Lumens: 3000
Spec Sheet:  113475000-00704990.pdf


Part No: 113476000-00704993
Model: WLA 3700/850/T
Length: 47.2"
Wattage: 43W
Lumens: 3700
Spec Sheet:  113476000-00704993.pdf


Part No: 113477000-00704996
Model: WLA 5000/850/T
Length: 59"
Wattage: 57W
Lumens: 5000
Spec Sheet:  113477000-00704996.pdf


Part NoModelLengthWattageLumensSpec SheetIES
113470000-00800170WLA 1100/85017.7"15W1100
113475000-00704990WLA 3000/850/T 35.4"37W3000
113476000-00704993WLA 3700/850/T 47.2"43W3700
113477000-00704996WLA 5000/850/T 59"57W5000
WLA Work bench light fixture, Workstation light fixture
WLA Work bench lighting, Workstation lighting
WLA Workstation light fixture, Work bench light fixture
WLA workstation lighting, work bench lighting


Description Part Number Image
Workbench / Workstation light bracket for WLA (included)  408109019-00728797
Workbench light connector cable for WLA, 1-ft for thru-wire  330691010-00577361
Workbench light connector cable for WLA, 10-ft for thru-wire  330691020-00630438
