DIRECT/INDIRECT LUMINAIRE | ZERA
The latest in LED technology, a self-contained housing and only the most durable components available make ZERA bed light a maintenance-free, fully functional lighting solution for medical facilities, senior residences, or any other public living or care-giving environment. ZERA bed light has three self- switchable lighting scenarios; ambient light to softly illuminate the general environment (3000K), a more focused examination light directed towards the bed area (4000K) and a glare-free reading light (2700K) for comfortable quiet time. Also available, a more basic version, combining general, ambient room light along with a reading light, and including dimming for custom comfort.
- Sleek straight lines for modern design
- Enclosed and sealed housing protects the inside workings of the light
- Internal LVC interface for pillow switch to nurse call station
- Strong examination light strategically directs light to aid in tending to the patient
- Several versions available to customize needs
- Three color temperatures for diverse applications
- 3000K general room lighting
- 4000K far-reaching examination light
- 2700K glare-free reading light
- Easy access to electrical connection and converters
- Meets EN 60598-2-25 standards
Spec Sheets
IES Files
Images
Accessories
Downloads
Spec Sheets
| Part No | Model Type | Wattage | Night Light | Controls | Voltage | Color Temperature | Spec Sheet | IES | |
|---|---|---|---|---|---|---|---|---|---|
| 1 | D15931000 | Zera Wall | 40W | No | Dimming | 120-277V | 4000K | Download | |
| 2 | D15448000 | Zera Wall VTL | 20W | No | Dimming | 120-277V | 3000 – 6500K | Download | |
| 3 | D15840000 | Zera Wall VTL | 50W | No | Dimming | 120-277V | 3000 – 6500K | Download | |
| 4 | D15968000 | Zera Bed Eco | 61W | Yes | On/Off | 120-277V | 3000K | Download | |
| 5 | D15856000 | Zera Wall | 40W | No | Dimming | 120-277V | 3000K | ||
| 6 | D15955000 | Zera Bed Eco | 61W | No | On/Off | 120-277V | 3000K | Download | |
| 7 | D15751002 | Zera Bed | 82W | No | With Low Voltage Controller | 120-277V | 2700K | Download | Download |
| 8 | D15751001 | Zera Bed | 82W | No | On/Off | 120-277V | 4000K / 3000K / 2700K | Download | Download |
| 9 | D15936000 | Zera Wall | 18W | No | Dimming | 120-277V | 3000K | ||
| 10 | D15751003 | Zera Bed | 82W | No | With Low Voltage Controller (dimming) | 120-277V | 4000K / 3000K / 2700K | Download | Download |
| 12 | D15699002 | ZERA Bed | 85W | Yes | With Low Voltage Controller | 120 V | 4000K / 3000K / 2700K | Download | |
| 13 | D15699702 | ZERA Bed | 85W | Yes | With Low Voltage Controller | 277 V | 4000K / 3000K / 2700K | ||
| 14 | D15751002 | ZERA Bed | 82W | Yes | With Low Voltage Controller | 120 V | 4000K / 3000K / 2700K | ||
| 15 | D15751702 | ZERA Bed | 82W | Yes | With Low Voltage Controller | 277 V | 4000K / 3000K / 2700K | ||
| 16 | D15955001 | ZERA Bed Eco | 61W | No | With Low Voltage Controller | 120 V | 3000 K | ||
| 17 | D15955701 | ZERA Bed Eco | 61W | No | With Low Voltage Controller | 277 V | 3000 K |
* There are many different options and possible configurations with these fixtures. The attached are our standard models.
